Hybrid Inverter – 48V 6.2KVA 6200W MPPT 120A Pure Sine Wave - Ecco

Key Features:

• Dual Output for Smart Load Management – Prioritize essential loads during power outages.
• Lithium Battery Activation Function – Activates via PV (solar) or utility power.
• Compatible with LiFePO4 Batteries – Seamless communication via RS485.
• High PV Input Capacity – Supports up to 500V DC input for optimal solar power conversion.
• Built-in MPPT 120A – Advanced solar charge controller for efficient energy use.
• Battery-Free Operation – Capable of running without a battery, making it versatile.
• Detachable Dust Cover – Designed for harsh environments to prevent dust buildup.
• WiFi Remote Monitoring (Optional) – Easily monitor system performance via a WiFi dongle.
• Multiple Output Priority Modes: Choose between UTL, SOL, SBU, and SUB to optimize energy distribution.
• EQ Function for Battery Optimization – Extends battery life and ensures peak performance.

What’s in the Box?

• 1x Ecco 6.2KVA Hybrid Inverter

100ah 5.12kWh Lithium Battery LW51.2-100 Wall-Mounted Leoch 51.2V

Features

• Compact Size
• Eco-Friendly
• Long Lifespan
• Built-in BMS
• Can be used in parralel with Ecco W51100 & ELV51100 Battery.

Product Introduction

Up to 15 groups of parallel connections, flexible
capacity expansion

APP can monitor battery SOC, voltage,
temperature, and other statuses

Compatible with mainstream inverters in the
market, providing more options

Built-in BMS provides multiple protection
functions

Specifications :

Model : LW51.2-100
Nominal Voltage : 51.2 V
Rated Capacity  : 100 Ah
Energy : 5.12 kWh
Discharge Ending Voltage : 43.2 V
Charging Limited Voltage : 58.4 V
Max. Charge/Discharge Current : 100 A
Weight Approx. 48 Kg
Dimensions (W*D*H) mm (inches) : 400 *560 *150 mm
Protocol : RS485/RS232/CAN
Max number of parallel connections : 15
Design life : More than 15 years
Cycle Life : More than 6000 cycles @ 80% DOD
IP Class : IP30
Case Material : SPCC
Operating Temperature Charging : 0 to +45℃ Discharging: -10 to +55℃ Storage: -20 to +60℃
Fuction : Bluetooth & WiFi

 Combo includes:

Complete Load Shedding Solution – What’s Included in the Combo?

• 1x Ecco 6.2KVA 6200W Hybrid Inverter (5-Year Warranty)
• 1x Ecco 51.2V 100Ah 5.12kWh Lithium Battery (5-Year Warranty)

Warranty Information – Important Notice

To ensure the validity of the 5-year warranty, installation must be carried out by a qualified electrical wireman or Master Electrician with valid registration from the Department of Labour.

A valid Electrical Certificate of Compliance (COC) must be issued after installation, specifically for the backup or solar system.
